The SUNMAS wireless heated TENS patch massager SM9086A combines low-frequency TENS stimulation and adjustable heating in a compact rechargeable device. It offers six TENS modes, 20 intensity levels and three heating levels. The magnetic connection allows the controller to attach directly to the supplied heating pad without external lead wires, while remote-control operation makes adjustment more convenient.
Product Overview
The SUNMAS wireless heated TENS patch massager SM9086A combines low-frequency TENS stimulation and adjustable heating in a compact rechargeable device. It offers six TENS modes, 20 intensity levels and three heating levels. The magnetic connection allows the controller to attach directly to the supplied heating pad without external lead wires, while remote-control operation makes adjustment more convenient.
Key Advantages
• Six TENS modes provide different low-frequency stimulation patterns for pain relief and body relaxation.
• Twenty intensity levels allow the stimulation strength to be increased gradually according to user preference.
• Three heating levels reach approximately 36°C, 37°C and 38°C after 20 minutes under the specified test conditions.
• TENS stimulation and heating can be used together or adjusted separately.
• Main-unit controls and remote-control operation provide flexible adjustment during use.
• Two RGB indicator lights show the selected TENS mode, heating level, charging status and low-battery warning.
• Load detection automatically returns the TENS intensity to level 0 when no load is detected.
• The rechargeable 800mAh battery and Type-C charging port support convenient cordless use.
Applications
This wireless heated TENS patch massager can be used on suitable areas such as the neck, shoulders, back, waist, arms, legs and joints. The combination of adjustable heat and TENS stimulation is designed to support pain relief, muscle relaxation and relief from everyday fatigue. Follow the product instructions for pad placement, temperature selection and intensity adjustment.
Why Choose SUNMAS
SUNMAS develops TENS, EMS and heated massage products for B2B customers. The SM9086A combines wireless use, adjustable heating, TENS stimulation and remote control in one portable device. OEM and ODM services are available for branding, packaging and product configuration.
| Attribute | Specification |
| Product Name | Wireless Heated TENS Patch Massager |
| Model No. | SM9086A |
| Application | Neck, shoulders, back, waist, arms, legs and joints |
| Main Function | TENS stimulation, adjustable heating, pain relief and body relaxation |
| TENS Modes | 6 Modes |
| Intensity Levels | 20 Levels |
| Heating | 3 Levels: 36°C ±2°C, 37°C ±2°C and 38°C ±2°C after 20 Minutes at 27°C Ambient Temperature |
| Timer | 20-Minute Heating Timer; TENS Output Runs Continuously |
| Control Method | Main Unit Button Control and Wireless Remote Control |
| Display | Two RGB LED Indicator Lights |
| Battery Capacity | 3.7V / 800mAh |
| Charging Port | Type-C |
| Charging Time | Approximately 3 Hours |
| Pulse Frequency | 1–100Hz ±10% |
| Pulse Width | 100–220μs ±10% |
| Load Detection | Supported; TENS Intensity Returns to Level 0 When No Load Is Detected |
| Product Dimensions | 77.5 × 43.5 × 15mm |
| Product Weight | 40g |
| Customization | OEM/ODM Available |
